BA-485B-LL

  • Two-Piece Brass Ball Valve, 600 WOG, Solder Ends
  • Not Intended for Use in Potable Water
  • Combination of Buna “O-Ring” and TFE Packing Requires Little or No Maintenance
  • 400 WOG (4″)

Product Documents

IOMs

Spec Sheets

Product Videos

Description

Material

Brass
ANSI/Pressure Rating

600 WOG
End Connection

Solder
Body Style

Two – Piece
Seat Material

RPTFE
Port

Full
Ball

Chrome Plated
Operator

Locking Lever Handle
Product Size

1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3"
Add to quote
Category:

Weights, Dimensions, and Box Quantity

Size
Unit Weight
Unit Dims.
LxWxH
Box Quantity
Box Dims.
LxWxH
1/2"
0.44
2.28 x 1 x 1.46
10
6.1811 x 4.8819 x 2.4409
3/4"
0.82
3.1 x 1.26 x 1.93
6
6.1811 x 5.1969 x 2.9528
1"
1.12
3.56 x 1.5 x 2.1
6
6.1811 x 6.4567 x 3.5039
1 1/4"
1.9
4.13 x 1.76 x 2.33
4
7.6378 x 5.0787 x 4.2126
1 1/2"
2.55
4.64 x 2 x 2.52
4
8.3465 x 5.8661 x 4.5669
2"
5.36
5.75 x 2.5 x 2.96
2
10.315 x 5.6693 x 3.5433
2 1/2"
9.9
7.25 x 2.98 x 3.94
1
11.9685 x 6.4173 x 4.6063
3"
14.5
8.25 x 0 x 4.37
1
12.6378 x 7.126 x 5.315
